| Description | • Spring type
• Stainless steel material | • Indicating bar is calibrated with 32nds on one side, other side is millimeters
• Has magnified sight-glass for easy readability
• Measures Tread Depth Up to 6 in
• Material: Aluminum | • Hardened and tempered blade
• Laser etched with inch and mm sizes | • Machined aluminum frame for accurate readings, solid block acrylic vials resist breaking or deformation
• 3 standard bubble vials, meets the needs of a multi-angle accurate measuring tool | • Hammertone, baked enamel finished frame
• Ratchet stop | • Carbide measuring faces |
| Content |
| Mfr.Pn |
Size (inch) |
Part Number |
| 258-4 |
4” |
MT0000078 |
| 258-6 |
6” |
MT0000081 |
| 258-8 |
8” |
MT0000084 |
| 258-10 |
10” |
MT0000087 |
| 258-12 |
12” |
MT0000090 |
| 258-15 |
15” |
MT0000093 |
| 258-18 |
18” |
MT0000096 |
| 258-24 |
24” |
MT0000099 |
| 258-36 |
36” |
MT0000102 |
|
| Mfr.PN |
Length(in) |
Calibration(in) |
Part Number |
| 335 |
7” |
0.0313” |
MT0000420 |
|
| Mfr.PN |
Length (inch) |
Blade Size |
No. Blades |
Part Number |
| 236-1 |
4” |
0.02 -1.00mm |
17 |
MT0000049 |
| 236-2 |
4” |
0.0015" - 0.025" |
26 |
MT0000050 |
| 236-6 |
6” |
0.02 - 1.00mm |
17 |
MT0000051 |
| 236-8 |
8” |
0.02 - 1.00mm |
17 |
MT0000052 |
| 236-12 |
12” |
0.02 - 1.00mm |
17 |
MT0000053 |
|
| Mfr.PN |
Size (inch) |
Size (mm) |
Part Number |
| 424-12 |
12” |
300 |
MT0000385 |
| 424-16 |
16" |
400 |
MT0000436 |
| 424-20 |
20“ |
500 |
MT0000431 |
| 424-24 |
24” |
600 |
MT0000389 |
| 424-32 |
32" |
800 |
MT0000437 |
| 424-40 |
40" |
1000 |
MT0000438 |
|
| Mfr.PN |
Size (mm) |
Accuracy (mm) |
Part Number |
| 232-25 |
0-25 |
±2μm |
MT0000109 |
| 232-50 |
25-50 |
±2μm |
MT0000110 |
| 232-75 |
50-75 |
±2μm |
MT0000111 |
| 232-100 |
75-100 |
±3μm |
MT0000112 |
| 232-125 |
100-125 |
±3μm |
MT0000113 |
| 232-150 |
125-150 |
±3μm |
MT0000416 |
| 232-175 |
150-175 |
±3μm |
MT0000429 |
| 232-200 |
175-200 |
±3μm |
MT0000430 |
|
| Mfr.PN |
Size (mm) |
Accuracy (mm) |
Part Number |
| 233-25 |
5 - 30 |
±5μm |
MT0000124 |
| 233-50 |
25 - 50 |
±6μm |
MT0000125 |
| 233-75 |
50 - 75 |
±7μm |
MT0000126 |
| 233-100 |
75 - 100 |
±8μm |
MT0000127 |
| 233-125 |
100 - 125 |
±9μm |
MT0000128 |
|
