| Description | • Made of super solid chrome molybdenum, with wear resistance and corrosionresistance. It has a solid structure, which will not break easily under high pressure,so as to obtain the maximum strength and life
• 6-point, high-torque socket design grips flat sides of fastener heads, not corners,preventing round-off | • Standard: Conforms to DIN 3121/ISO 1174
• Hardened & tempered to 40-45 HRC
• Material: Chrome Molybdenum Steel
• Size 200 & 300mm with ball retainer, 400mm without ball retainer | • Hardened & tempered to 50-58 HRC
• Material: Chrome Molybdenum Steel | • Suitable for use in awkward areas, swivel angle up to 30°
• Extra long pattern for difficult to reach areas
• High torque ability and impact resistance suitable for heavy duty use
• Material: 59 CrMoV 4
• Standard: Conforms to DIN 911/ISO 2936
[video width="1920" height="1080" mp4="https://startoolsindonesia.com/wp-content/uploads/2023/10/Extra-Long-Ball-End-Hex-Key.mp4" poster="https://startoolsindonesia.com/wp-content/uploads/2023/10/Extra-Long-Ball-End-Hex-Key.jpg"][/video] | • For use with air or electric power tools
• Standard: Conforms to DIN 3129/ISO 2725, DIN 3121/ISO 1174
• Hardened & tempered to 40-45 HRC
• Material: Chrome Molybdenum Steel | • Exceeds DIN torque requirement by 30%
• Material: 31 CrV 3 Chrome Vanadium Steel
• Standard: Conforms to DIN 3124/ISO 2725
[video width="1920" height="1080" mp4="https://startoolsindonesia.com/wp-content/uploads/2023/10/6-Pt-Hand-Socket.mp4" poster="https://startoolsindonesia.com/wp-content/uploads/2023/10/6pt.jpg"][/video] |
| Content |
| Mfr.PN |
Description |
Size |
Part Number |
| 166S-26 |
3/4"Dr. 6PT Impact Socket |
21mm • 22mm • 23mm • 24mm •
26mm • 27mm • 28mm • 29mm •
30mm • 31mm • 32mm • 33mm •
34mm • 36mm • 38mm • 41mm •
46mm • 50mm • 55mm • 60mm |
HT0003770 |
|
3/4” Impact Extension Bar |
4”, 6” |
|
|
3/4” Ratchet Handle |
|
|
|
1"Dr. Sliding Head |
|
|
|
3/4"Dr. L Handle |
|
|
|
| Mfr.PN |
Length(mm) |
Part Number |
| 173-150 |
150 |
HT0003728 |
| 173-200 |
200 |
HT0002272 |
| 173-250 |
250 |
HT0003602 |
| 173-300 |
300 |
HT0002273 |
| 173-400 |
400 |
HT0002274 |
|
| Mfr.PN |
Sq Drive(in) |
Length(mm) |
Part Number |
| 369ST |
1.1/2" |
980 |
HT00003497 |
|
| Mfr.PN |
Size(mm) |
Size(in) |
L1(mm) |
L2(mm) |
Part Number |
| 108BL-1.5 |
1.5 |
|
15.5 |
91.5 |
HT0001126 |
| 108BL-2 |
2.0 |
|
18.0 |
102.0 |
HT0001127 |
| 108BL-2.5 |
2.5 |
|
20.5 |
114.0 |
HT0001128 |
| 108BL-3 |
3.0 |
|
23.0 |
129.0 |
HT0001129 |
| 108BL-4 |
4.0 |
|
29.0 |
144.0 |
HT0001130 |
| 108BL-5 |
5.0 |
|
33.0 |
165.0 |
HT0001131 |
| 108BL-6 |
6.0 |
|
38.0 |
186.0 |
HT0001132 |
| 108BL-8 |
8.0 |
|
44.0 |
208.0 |
HT0001133 |
| 108BL-10 |
10.0 |
|
50.0 |
234.0 |
HT0001134 |
| 108BL-12 |
12.0 |
|
57 |
219 |
HT0001135 |
| 108BL-14 |
14.0 |
|
70 |
244 |
HT0001136 |
| 108BL-17 |
17.0 |
|
78 |
257 |
HT0001137 |
| 108BL-19 |
19.0 |
|
83 |
336 |
HT0003469 |
| 108BL-22 |
22.0 |
|
95 |
388 |
HT0003470 |
| 108BL-24 |
24.0 |
|
105 |
431 |
HT0003471 |
| 108BLA-1/16 |
|
1/16" |
18.0 |
91.0 |
HT0001138 |
| 108BLA-5/64 |
|
5/64" |
19.0 |
102.0 |
HT0001139 |
| 108BLA-3/32 |
|
3/32" |
21.0 |
114.0 |
HT0001140 |
| 108BLA-1/8 |
|
1/8" |
24.0 |
129.0 |
HT0001141 |
| 108BLA-5/32 |
|
5/32" |
27.0 |
144.0 |
HT0001142 |
| 108BLA-3/16 |
|
3/16" |
30.0 |
165.0 |
HT0001143 |
| 108BLA-1/4 |
|
1/4" |
37.0 |
186.0 |
HT0001144 |
| 108BLA-5/16 |
|
5/16" |
42.0 |
208.0 |
HT0001145 |
| 108BLA-3/8 |
|
3/8" |
46.0 |
234.0 |
HT0001146 |
|
| Mfr.PN |
Size |
Length(mm) |
Part Number |
| 163TX-20 |
T20 |
78 |
HT0002013 |
| 163TX-25 |
T25 |
78 |
HT0002014 |
| 163TX-27 |
T27 |
78 |
HT0002015 |
| 163TX-30 |
T30 |
78 |
HT0002016 |
| 163TX-40 |
T40 |
78 |
HT0002017 |
| 163TX-45 |
T45 |
78 |
HT0002018 |
| 163TX-50 |
T50 |
78 |
HT0002019 |
| 163TX-55 |
T55 |
78 |
HT0002020 |
| 163TX-60 |
T60 |
78 |
HT0002021 |
| 163-TX70 |
T70 |
78 |
HT0003638 |
| 163-TX80 |
T80 |
78 |
HT0003639 |
| 163-TX90 |
T90 |
78 |
HT0003640 |
| 163-TX100 |
T100 |
78 |
HT0003641 |
|
| Mfr.PN |
Size(mm) |
Size(in) |
Length(mm) |
Part Number |
| 110-4 |
4 |
|
25 |
HT0001325 |
| 110-4.5 |
4.5 |
|
25 |
HT0001326 |
| 110-5 |
5 |
|
25 |
HT0001327 |
| 110-5.5 |
5.5 |
|
25 |
HT0001328 |
| 110-6 |
6 |
|
25 |
HT0001329 |
| 110-7 |
7 |
|
25 |
HT0001330 |
| 110-8 |
8 |
|
25 |
HT0001331 |
| 110-9 |
9 |
|
25 |
HT0001332 |
| 110-10 |
10 |
|
25 |
HT0001333 |
| 110-11 |
11 |
|
25 |
HT0001334 |
| 110-12 |
12 |
|
25 |
HT0001335 |
| 110-13 |
13 |
|
25 |
HT0001336 |
| 110-14 |
14 |
|
25 |
HT0001337 |
| 110A-5/32 |
|
5/32" |
25 |
HT0001338 |
| 110A-3/16 |
|
3/16" |
25 |
HT0001339 |
| 110A-7/32 |
|
7/32" |
25 |
HT0001340 |
| 110A-1/4 |
|
1/4" |
25 |
HT0001341 |
| 110A-9/32 |
|
9/32" |
25 |
HT0001342 |
| 110A-5/16 |
|
5/16" |
25 |
HT0001343 |
| 110A-3/8 |
|
3/8" |
25 |
HT0001344 |
| 110A-7/16 |
|
7/16" |
25 |
HT0001345 |
| 110A-1/2 |
|
1/2" |
25 |
HT0001346 |
| 110A-9/16 |
|
9/16" |
25 |
HT0001347 |
|
