| Description | • Hardened and tempered blade
• Laser etched with inch and mm sizes | • Two-point contact for detection of geometry problems such as ovality and taper
• Carbide-tipped contact points for extended wear and improved abrasion resistance
• Includes all the necessary spacers, interchangeable extensions and ABS storage case | • Accuracy: DIN862
• Made of stainless steel
• Satin chrome finish
• Raised sliding faces | • Spring type
• Stainless steel material | • Machined aluminum frame for accurate readings, solid block acrylic vials resist breaking or deformation
• 3 standard bubble vials, meets the needs of a multi-angle accurate measuring tool | • Hammertone, baked enamel finished frame
• Ratchet stop |
| Content |
| Mfr.PN |
Length (inch) |
Blade Size |
No. Blades |
Part Number |
| 236-1 |
4” |
0.02 -1.00mm |
17 |
MT0000049 |
| 236-6 |
4” |
0.02 - 1.00mm |
32 |
MT0000445 |
| 236-3 |
6” |
0.02 - 1.00mm |
17 |
MT0000051 |
| 236-4 |
8” |
0.02 - 1.00mm |
17 |
MT0000052 |
| 236-5 |
12” |
0.02 - 1.00mm |
17 |
MT0000053 |
| 236-2 |
4" |
0.0015" - 0.025" |
26 |
MT0000050 |
|
| Mfr.PN |
Size(mm) |
Graduation (mm) |
Part Number |
| 351-35 |
18-35 |
0.01 |
MT0000424 |
| 351-50 |
35-50 |
0.01 |
MT0000425 |
| 351-160 |
50-160 |
0.01 |
MT0000417 |
| 351-250 |
150-250 |
0.01 |
MT0000418 |
| 351-400 |
250-400 |
0.01 |
MT0000419 |
|
| Mfr.PN |
Size (mm) |
Size (inch) |
Accuracy |
Part Number |
| 231-6 |
150 |
6” |
0.02mm |
MT0000074 |
| 483-6 |
150 |
6" |
0.05mm |
MT0000441 |
| 231-8 |
200 |
8” |
0.02mm |
MT0000075 |
| 483-8 |
200 |
8" |
0.05mm |
MT0000442 |
| 231-12 |
300 |
12" |
0.02mm |
MT0000076 |
| 483-12 |
300 |
12" |
0.05mm |
MT0000443 |
|
| Mfr.Pn |
Size (inch) |
Part Number |
| 258-4 |
4” |
MT0000078 |
| 258-6 |
6” |
MT0000081 |
| 258-8 |
8” |
MT0000084 |
| 258-10 |
10” |
MT0000087 |
| 258-12 |
12” |
MT0000090 |
| 258-15 |
15” |
MT0000093 |
| 258-18 |
18” |
MT0000096 |
| 258-24 |
24” |
MT0000099 |
| 258-36 |
36” |
MT0000102 |
|
| Mfr.PN |
Size (inch) |
Size (mm) |
Part Number |
| 424-12 |
12” |
300 |
MT0000385 |
| 424-16 |
16" |
400 |
MT0000436 |
| 424-20 |
20“ |
500 |
MT0000431 |
| 424-24 |
24” |
600 |
MT0000389 |
| 424-32 |
32" |
800 |
MT0000437 |
| 424-40 |
40" |
1000 |
MT0000438 |
|
| Mfr.PN |
Size (mm) |
Part Number |
| 232S-150 |
0-150 |
MT0000435 |
|
