| Description | • Exceeds DIN torque requirement by 30%
• Material: 31 CrV 3 Chrome Vanadium Steel
• Standard: Conforms to DIN 3124/ISO 2725
[video poster="https://startoolsindonesia.com/wp-content/uploads/2023/10/12pt.jpg" width="1920" height="1080" mp4="https://startoolsindonesia.com/wp-content/uploads/2023/10/12PT-Hand-Socket.mp4"][/video] | • Extra long pattern for difficult to reach areas
• High torque ability and impact resistance suitable for heavy duty use
• Material: 59 CrMoV 4
• Standard: Conforms to DIN 911/ISO 2936
[video width="1920" height="1080" mp4="https://startoolsindonesia.com/wp-content/uploads/2023/10/Extra-Long-Hex-Key.mp4" poster="https://startoolsindonesia.com/wp-content/uploads/2023/10/Extra-Long-Hex-Key-1.jpg"][/video] | • For use with air or electric power tools
• Standard: Conforms to DIN 3129/ISO 2725, DIN 3121/ISO 1174
• Hardened & tempered to 40-45 HRC
• Material: Chrome Molybdenum Steel | • High torque ability and impact resistance suitable for heavy duty use
• Material: 59 CrMoV 4
• Standard: Conforms to DIN 911/ISO 2936
[video width="1920" height="1080" mp4="https://startoolsindonesia.com/wp-content/uploads/2023/10/Hex-Key-Wrench.mp4" poster="https://startoolsindonesia.com/wp-content/uploads/2023/10/Hex-Key-Wrench.jpg"][/video] | • For use with air or electric power tools
• Standard: Conforms to DIN 3129/ISO 2725, DIN 3121/ISO 1174
• Hardened & tempered to 40-45 HRC
• Material: Chrome Molybdenum Steel | • Suitable for use in awkward areas, swivel angle up to 30°
• Extra long pattern for difficult to reach areas
• High torque ability and impact resistance suitable for heavy duty use
• Material: 59 CrMoV 4
• Standard: Conforms to DIN 911/ISO 2936
[video width="1920" height="1080" mp4="https://startoolsindonesia.com/wp-content/uploads/2023/10/Extra-Long-Ball-End-Hex-Key.mp4" poster="https://startoolsindonesia.com/wp-content/uploads/2023/10/Extra-Long-Ball-End-Hex-Key.jpg"][/video] |
| Content |
| Mfr.PN |
Size(mm) |
Length(mm) |
Part Number |
| 151-36 |
36 |
65 |
HT0001873 |
| 151-41 |
41 |
70 |
HT0001874 |
| 151-46 |
46 |
75 |
HT0001875 |
| 151-50 |
50 |
75 |
HT0001876 |
| 151-55 |
55 |
80 |
HT0001877 |
| 151-60 |
60 |
84 |
HT0001878 |
| 151-65 |
65 |
87 |
HT0001879 |
| 151-70 |
70 |
93 |
HT0001880 |
| 151-75 |
75 |
97 |
HT0001881 |
| 151-80 |
80 |
103 |
HT0001882 |
|
| Mfr.PN |
Size(mm) |
Size(in) |
L1(mm) |
L2(mm) |
Part Number |
| 108L-1.5 |
1.5 |
|
15.5 |
91.5 |
HT0001147 |
| 108L-2 |
2.0 |
|
18.0 |
102.0 |
HT0001148 |
| 108L-2.5 |
2.5 |
|
20.5 |
114.5 |
HT0001149 |
| 108L-3 |
3.0 |
|
23.0 |
129.0 |
HT0001150 |
| 108L-4 |
4.0 |
|
29.0 |
144.0 |
HT0001151 |
| 108L-5 |
5.0 |
|
33.0 |
165.0 |
HT0001152 |
| 108L-6 |
6.0 |
|
38.0 |
186.0 |
HT0001153 |
| 108L-8 |
8.0 |
|
44.0 |
208.0 |
HT0001154 |
| 108L-10 |
10.0 |
|
50.0 |
234.0 |
HT0001155 |
| 108LA-1/16 |
|
1/16" |
18.0 |
91.0 |
HT0001156 |
| 108LA-5/64 |
|
5/64" |
19.0 |
102.0 |
HT0001157 |
| 108LA-5/32 |
|
3/32" |
21.0 |
114.0 |
HT0001158 |
| 108LA-1/8 |
|
1/8" |
24.0 |
129.0 |
HT0001159 |
| 108LA-5/32 |
|
5/32" |
27.0 |
144.0 |
HT0001160 |
| 108LA-3/16 |
|
3/16" |
30.0 |
165.0 |
HT0001161 |
| 108LA-1/4 |
|
1/4" |
37.0 |
186.0 |
HT0001162 |
| 108LA-5/16 |
|
5/16" |
42.0 |
108.0 |
HT0001163 |
| 108LA-3/8 |
|
3/8" |
46.0 |
234.0 |
HT0001164 |
|
| Mfr.PN |
Size(mm) |
Length(mm) |
Part Number |
| 171-14 |
14 |
100 |
HT0002262 |
| 171-17 |
17 |
100 |
HT0002263 |
| 171-19 |
19 |
100 |
HT0002264 |
| 171-22 |
22 |
100 |
HT0002265 |
| 171-24 |
24 |
100 |
HT0002266 |
| 171-27 |
27 |
100 |
HT0002267 |
| 171-30 |
30 |
100 |
HT0002268 |
| 171-32 |
32 |
100 |
HT0002269 |
|
| Mfr.PN |
Size(mm) |
Size(in) |
L1(mm) |
L2(mm) |
Part Number |
| 108-1.5 |
1.5 |
|
15.5 |
46.5 |
HT0001027 |
| 108-2 |
2.0 |
|
18.0 |
52.0 |
HT0001028 |
| 108-2.5 |
2.5 |
|
20.5 |
58.5 |
HT0001029 |
| 108-3 |
3.0 |
|
23.0 |
66.0 |
HT0001030 |
| 108-4 |
4.0 |
|
29.0 |
74.0 |
HT0001031 |
| 108-5 |
5.0 |
|
33.0 |
85.0 |
HT0001032 |
| 108-6 |
6.0 |
|
38.0 |
96.0 |
HT0001033 |
| 108-8 |
8.0 |
|
44.0 |
108.0 |
HT0001034 |
| 108-10 |
10.0 |
|
50.0 |
122.0 |
HT0001035 |
| 108-12 |
12.0 |
|
57.0 |
137.0 |
HT0001036 |
| 108-14 |
14.0 |
|
70.0 |
154.0 |
HT0001037 |
| 108-17 |
17.0 |
|
80.0 |
177.0 |
HT0001038 |
| 108-19 |
19.0 |
|
89.0 |
199.0 |
HT0001039 |
| 108-22 |
22.0 |
|
102.0 |
222.0 |
HT0001040 |
| 108A-1/16 |
|
1/16" |
18.0 |
46.0 |
HT0001041 |
| 108A-5/64 |
|
5/64" |
19.0 |
50.0 |
HT0001042 |
| 108A-3/32 |
|
3/32" |
21.0 |
53.0 |
HT0001043 |
| 108A-1/8 |
|
1/8" |
24.0 |
59.0 |
HT0001044 |
| 108A-5/32 |
|
5/32" |
27.0 |
65.0 |
HT0001045 |
| 108A-3/16 |
|
3/16" |
30.0 |
72.0 |
HT0001046 |
| 108A-1/4 |
|
1/4" |
37.0 |
84.0 |
HT0001047 |
| 108A-5/16 |
|
5/16" |
42.0 |
97.0 |
HT0001048 |
| 108A-3/8 |
|
3/8" |
46.0 |
110.0 |
HT0001049 |
|
| Mfr.PN |
Size |
Length(mm) |
Part Number |
| 163TX-20 |
T20 |
78 |
HT0002013 |
| 163TX-25 |
T25 |
78 |
HT0002014 |
| 163TX-27 |
T27 |
78 |
HT0002015 |
| 163TX-30 |
T30 |
78 |
HT0002016 |
| 163TX-40 |
T40 |
78 |
HT0002017 |
| 163TX-45 |
T45 |
78 |
HT0002018 |
| 163TX-50 |
T50 |
78 |
HT0002019 |
| 163TX-55 |
T55 |
78 |
HT0002020 |
| 163TX-60 |
T60 |
78 |
HT0002021 |
| 163-TX70 |
T70 |
78 |
HT0003638 |
| 163-TX80 |
T80 |
78 |
HT0003639 |
| 163-TX90 |
T90 |
78 |
HT0003640 |
| 163-TX100 |
T100 |
78 |
HT0003641 |
|
| Mfr.PN |
Size(mm) |
Size(in) |
L1(mm) |
L2(mm) |
Part Number |
| 108BL-1.5 |
1.5 |
|
15.5 |
91.5 |
HT0001126 |
| 108BL-2 |
2.0 |
|
18.0 |
102.0 |
HT0001127 |
| 108BL-2.5 |
2.5 |
|
20.5 |
114.0 |
HT0001128 |
| 108BL-3 |
3.0 |
|
23.0 |
129.0 |
HT0001129 |
| 108BL-4 |
4.0 |
|
29.0 |
144.0 |
HT0001130 |
| 108BL-5 |
5.0 |
|
33.0 |
165.0 |
HT0001131 |
| 108BL-6 |
6.0 |
|
38.0 |
186.0 |
HT0001132 |
| 108BL-8 |
8.0 |
|
44.0 |
208.0 |
HT0001133 |
| 108BL-10 |
10.0 |
|
50.0 |
234.0 |
HT0001134 |
| 108BL-12 |
12.0 |
|
57 |
219 |
HT0001135 |
| 108BL-14 |
14.0 |
|
70 |
244 |
HT0001136 |
| 108BL-17 |
17.0 |
|
78 |
257 |
HT0001137 |
| 108BL-19 |
19.0 |
|
83 |
336 |
HT0003469 |
| 108BL-22 |
22.0 |
|
95 |
388 |
HT0003470 |
| 108BL-24 |
24.0 |
|
105 |
431 |
HT0003471 |
| 108BLA-1/16 |
|
1/16" |
18.0 |
91.0 |
HT0001138 |
| 108BLA-5/64 |
|
5/64" |
19.0 |
102.0 |
HT0001139 |
| 108BLA-3/32 |
|
3/32" |
21.0 |
114.0 |
HT0001140 |
| 108BLA-1/8 |
|
1/8" |
24.0 |
129.0 |
HT0001141 |
| 108BLA-5/32 |
|
5/32" |
27.0 |
144.0 |
HT0001142 |
| 108BLA-3/16 |
|
3/16" |
30.0 |
165.0 |
HT0001143 |
| 108BLA-1/4 |
|
1/4" |
37.0 |
186.0 |
HT0001144 |
| 108BLA-5/16 |
|
5/16" |
42.0 |
208.0 |
HT0001145 |
| 108BLA-3/8 |
|
3/8" |
46.0 |
234.0 |
HT0001146 |
|
